Dimensions (excluding antenna connectors and mounting accessories) |
250 × 101 × 110 mm |
|
Fixed port |
2 × 10/100/1000M electrical port |
|
Power supply |
PoE injector |
|
Built-in antenna |
Internal Omni-directional antenna 3dBi antenna gain @2.4GHz 5dBi antenna gain @5GHz |
|
Working frequencies |
802.11ax/ac/n/a: 5.725 GHz - 5.850 GHz; 5.47 GHz - 5.725 GHz; 5.15 GHz - 5.35 GHz 802.11ax/b/g/n: 2.4 GHz - 2.483 GHz |
|
Modulation technology |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps MIMO-OFDM(11n): MCS 0-15 MIMO-OFDM(11ac): MCS 0-9 MIMO-OFDM(11ax): MCS 0-11 |
|
Modulation mode |
11b: DSS:CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM:64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM 11ac/ac wave2: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
|
Transmit power (combined power) |
23 dBm (Varies depending on local laws and regulations) |
|
Adjustable power granularity |
1 dBm |
|
Power consumption |
≤16.32W |
|
Reset/restoration to factory default |
Supported |
|
State LED |
Alternating flashing mode, orange/green/blue for different working states, breathing mode |
|
Operating temperature/storage temperature |
-30ºC to +55ºC/-40ºC to +70ºC |
|
Operating humidity/storage humidity |
0% - 100% (non-condensing) |
|
Protection degree |
IP67 |
|
Safety compliance |
GB 4943, EN/IEC/UL 60950-1, EN/IEC/UL 62368-1 |
|
EMC |
EN 55024, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 60601-1-2, EN 301 489-1, EN 301 489-17 |
|
Environment |
GB/T 2423, GB/T 13543, GB 4208 |
|
Radio frequency certification |
FCC Part 15, EN 300 328, EN 301 893, and MIIT SRRC |
|
MTBF |
2266650H |
